THE SUNDIALS AT LITLINGTON CHURCH, EAST SUSSEX (2)

Published on August 10, 2018August 10, 2018 by Rolling Harbour2 Comments

The remarkable, sophisticated and possibly unique scratch dial on the face of the church porch that I recently featured HERE is not the only dial on this attractive Sussex Church. Almost unremarked are what are passingly mentioned in the only two references I have found online as ‘two further sundials on a north buttress’ (a nod here to the Eastbourne Church Recording Group). These dials do not even appear in the British Sundial Society‘s list of mass / scratch dials (though they do feature the main dial on the porch).

DIAL ONE – NORTHEAST FACE

Having been told about the three – three! – dials, I was fairly confident when I set out to search for them. The first one – on the porch – was easy, not least because it was on the most obvious, south-facing, location possible. Then the trouble started. Without the Church Warden’s aid, I’d never ever have found the other 2. Who would guess that the dials would be (a) on the north side, (b) a couple of feet off the ground and (c) set at a 90º angle to each other on the same stone block in a buttress.

Northeast Face (1) Litlington Church, East Sussex: the sundials (Keith Salvesen)

In the absence of any other information, dating these dials is very hard. The church dates from c1150. These dials, almost identical in construction as far as one can tell, are clearly simpler and far cruder than the main dial on the porch that is dated to the c15 and is transitional in scratch dial design between showing canonical hours and the ‘modern’ 24 hour clock. Yet both dials are full circles, and have 24 ‘dots’ surrounding the central hole for the pointer – notwithstanding that only the ‘daytime’ area on each dial is functional in practice. As far as I can make out, this is not an unusual arrangement.

Northeast Face (2) Litlington Church, East Sussex: the sundials (Keith Salvesen)

DIAL TWO – NORTHWEST FACE

It’s hard to find any significant difference between this dial and its adjacent counterpart, other than the direction faced. I didn’t make any measurements, but this 24 dot dial seems smaller, not least because the available space on this face is less. The assumption must be that both dials were made at around the same time, presumably to catch the early morning and late afternoon sun. I’ve no idea why they were located so low on the building, since there are higher cornerstones on this buttress that would have done as well – and perhaps have been more readable at eye-level.

Litlington Church, East Sussex: the sundials (Keith Salvesen)

Sundials are an interest but very far from a speciality for me. If anyone can shed any light on dials of this sort – date, construction / design, location on the building – please comment on this post, or email me at rollingharbour.delphi [at] gmail.com. And if you know of a similar dial, please get in touch.

Litlington Church, East Sussex: the sundials (Keith Salvesen)

LITLINGTON SUNDIAL 1

All photos Keith Salvesen / Rolling Harbour

THE SUNDIALS AT LITLINGTON CHURCH, EAST SUSSEX (1)

Published on July 26, 2018July 30, 2018 by Rolling Harbour2 Comments

The majority of churches have no integral sundial. Those that do are usually content with one; some may supplement that with a standing sundial in the churchyard. Very few have three sundials that are integral to the building itself and to its history. The small church of Litlington East Sussex is one such. It also has a large benchmark on the porch, and three superb bells dating from the early c15. The main sundial is easy to spot; the other two are far less visible. I spent sometime looking for them in vain, until the church warden took pity on me. But (*spoiler alert*) whoever would expect to find sundials low down on a north wall? They deserve a post in their own right, which will form part 2. They are so far undocumented as far as I can see, except locally.

The church dates from c1150, and was restored in the mid-c19. The porch is where the quest for the main sundial ends – the benchmark, too.

St Michael's Church - sundial & benchmark. Litlington East Sussex (Keith Salvesen)

A close inspection shows just how unusual this scratch dial is – quite possibly unique. The only full account of it that I have found appears in an article by W. Oliver published in SCM* Volume 12 1938 Page 529. The link is given below.

St Michael's Church, Litlington East Sussex (Keith Salvesen)

There are 3 features that immediately stand out: the deep ‘furrow’ at 12 noon; the confusing style / pointer holes; and in particular the carefully graduated hour markings.

An improvised biro ‘style’ indicates the correct time

A REMARKABLE DIAL

W. Oliver makes several points in his article, which distilled come to this:

This is a scratch dial typical of Saxon times and the middle ages, incised on the building stones
The design (for the period) is “most exceptional, if not unique” among the 1400 recorded church scratch dials
Other dials have equally spaced hour-lines that cannot measure time accurately, and certainly not year-long (though pointer adjustments could be made to compensate)
These were primarily intended to indicate the 5 Canonical hours for prayer, not time
Extra lines were sometimes added, as time measurement became more sophisticated
At Litlington, exceptionally, the hour-line spacing is ‘scientific’ to enable accuracy
The lines are carefully graduated down to and up from 12 noon
This scientific approach is very much as seen on modern vertical sundials
The usual hole for a style / pointer is supplemented by the deeper groove at noon
This suggests there was at some stage a slanting gnomon, as found on modern wall dials
This could have been set to the latitude of Litlington to ensure year-round accuracy
The Litlington scratch dial may in fact be the only one able to tell the time properly

Church Sundial at Litlington By W. Oliver http://www.massdials.org.uk/texts/scm12.htm

Do the 3 holes support the theory of an added gnomon fixed below the original style hole?

DATING THE DIAL

W. Oliver does not give a date for the dial, other than ‘Middle Ages’ (it’s clearly not as old as Saxon). In a website called https://www.bestofengland.com the entry for this church states “Outside there is still a 13th century sundial on the porch”. This dating seems to have caught on and appears in e.g. Tripadvisor descriptions.

The local website http://www.litlington.info/st-michael-the-archangel-church-litlington says “Outside, on the porch, is a 15^th century scientific sundial…” Given the sophistication of the Litlington dial, the first date seems clearly wrong and the second must be the preferred date. It also fits in with date of the installation of the earliest bell – perhaps a time of general improvements to the church. Even so, in the light of W. Oliver’s analysis, the dial shows an extraordinary understanding of the principles of recording time accurately that is apparently absent in the 1399 other instances of scratch dials in the country. The British Sundial Society has a short entry (see below) for this dial (and none for the other two at the ‘back’ of this church, mentioned earlier), including a reference to a polar gnomon. No mention of a possible date, but I take ‘transitional’ to mean between the era of marking the Canonical Hours and the gradual move to a 12 / 24 hour clock as the standard for time-telling.

BRITISH SUNDIAL SOCIETY

The brief entry states “The dial can be seen to the right of the porch. All hour lines 6am – 6pm, but no numbers or any trace that there ever were any. Lines correctly delineated for a polar gnomon. No trace of old lines, so possibly not a re-cut mass dial. 310 diam. semicircle. Transitional dial? Ref. C Daniel, Sundials, Shire Album 176,1986, p5 Location 50°47’50″N, 0°9’34″E; National Grid: TQ 523 020″

The illustration to W. Oliver’s article

Any comments about this remarkable dial would be welcome.

Research as specified / linked. * = Sussex County Magazine. The Litlington website entry is as recorded by the Eastbourne Church Recording Group between 2007/2009. All photos Keith Salvesen / Rolling Harbour except as indicated
